D2 /1.2379 /1.2080/1.2436/1.2550
Typical uses are long run blanking, stamping, and cold forming dies; lamination dies; thread rolling dies; trimmer dies; slitters; brick mold liners; Work Rolls.
Very good wear resistance
High pressure resistance
Great toughness
Avaiable Size
| PRODUCT | DELIVERY CONDITION AND AVAILABLE DIMENSIONS | |||
| ROUND | COLD DRAWN | CENTERLESS GROUND | PEELED | TURNED |
| DIAMETER IN MM | 2.50 - 12.0 | 8.5 - 30.0 | 16 - 75 | 75 - 410 |
| SQUARE | HOT ROLLED BLACK | FORGED ALL SIDE MILLED | ||
| SIZE IN MM | 7.5 X 7.5 - 50.0 X 50.0 | 55 X 55 - 410 X 410 | ||
| FLATS | HOT ROLLED BLACK | HOT ROLLED, 2 EDGE MILLED | FORGED ALL SIDE MILLED | |
| THICK x WIDTH IN MM | 6 - 30 X 20 - 130 | 13 - 80 X 150 - 410 | 90 - 405 X 100 - 810 | |
| SHEET | COLD ROLLED | HOT ROLLED | ||
| THICK x WIDTH xLENGTH IN MM | 1.0 - 2.5 X 600 - 800 X 1500 - 2000 | 2.60 - 10 X 600 - 800 X 1500 - 2000 | ||
| DISC | 400 - 600 MM DIA X 80 - 300 THICK | |||
